Multi-Family Home Plan, 051M-0002
All images are copyrighted by our designers. Photos may reflect modifications made by the builder/homeowner.
Dressed with relaxed country charm, this unique multi-family house plan provides comfortable living for the home owner on the main floor with a private unit above for the in-laws, tenants, or boomerang children that have come back home to live with mom and dad for a while. Both units enter from the covered, wrap-around porch. On the first floor, Unit A boasts an open floor plan with step-saver kitchen, utility room, three bedrooms and two full baths. A detached, two-car garage polishes off Unit A. On the second floor, the kitchen flows nicely into the great room and living area accommodating everyday happenings. Two bedrooms and a full bath complete this modest, yet efficient unit. With the outward appearance of a single-family, two-story home, this duplex home plan blends well in most neighborhoods.
Unit A: Total – 1267 sf, 3 bedrooms, 2 baths, 2-car garage – 572 sf
Unit B: Total – 1021 sf, 2 bedrooms, 1 bath
| Heated Square Feet | |
| First Floor | 1267 |
| Second Floor | 1021 |
| Total | 2288 |
| Width | 47 ft. 0 in. |
| Depth | 45 ft. 0 in. |
| Approximate Height | 27 ft. 0 in. |
| Ceiling Height | |
| First Floor | 9 ft. 0 in. |
| Roof Pitch | 10/12 Main |
| Roof Framing |
|
| Foundation Options |
|
| Exterior Wall Options |
|
| Interior Features |
|
| Exterior Features |
|
Dressed with relaxed country charm, this unique multi-family house plan provides comfortable living for the home owner on the main floor with a private unit above for the in-laws, tenants, or boomerang children that have come back home to live with mom and dad for a while. Both units enter from the covered, wrap-around porch. On the first floor, Unit A boasts an open floor plan with step-saver kitchen, utility room, three bedrooms and two full baths. A detached, two-car garage polishes off Unit A. On the second floor, the kitchen flows nicely into the great room and living area accommodating everyday happenings. Two bedrooms and a full bath complete this modest, yet efficient unit. With the outward appearance of a single-family, two-story home, this duplex home plan blends well in most neighborhoods.
Unit A: Total – 1267 sf, 3 bedrooms, 2 baths, 2-car garage – 572 sf
Unit B: Total – 1021 sf, 2 bedrooms, 1 bath
Purchased as PDF or CAD file
PDF and CAD files are delivered by email, and have no shipping and handling cost.
Purchased as paper plans
* Scroll right to view table
| Continental US | Canada | AK/HI | *International | |
|---|---|---|---|---|
| Regular 8 - 12 business days | $30 | n/a | n/a | n/a |
| Priority 3 - 4 business days | $70 | n/a | n/a | n/a |
| Express 1 - 2 business days | n/a | n/a | n/a | n/a |
