Multi-Generational House Plan, 065H-0147

Plan 065H-0147
Reverse All Images
All images are copyrighted by our designers. Photos may reflect modifications made by the builder/homeowner.

The basement square footage includes the full area under the garage which calls for suspended concrete above
The basement is designed with a portion to be used by the main floor and a portion to be used as a separate apartment



Heated Square Feet
First Floor 2137
Lower Level 3568
Total 5705
Unheated Square Feet
Garage 1597
Porch(es) 399
Bedrooms 6
Full Bathrooms 4
Half Bathrooms 1
Width 76 ft. 3 in.
Depth 64 ft. 0 in.
Approximate Height 20 ft. 3 in.
Ceiling Height
First Floor 9 ft. 0 in.
Lower Level 9 ft. 0 in.
Roof Pitch 5/12 Main
Roof Framing
  • Truss
Garage Door Size(s) 18x8
Garage Door Size(s) 12x8
Foundation Options
  • Basement
Exterior Wall Options
  • 2x6
Kitchen Features
  • Eating/Snack bar
  • Island
  • Walk-in Pantry
Bedroom Features
  • Guest/In-law suite
  • Walk-in closet
Interior Features
  • Den/office/study
  • Family room
  • Hobby/rec room
  • Laundry
  • Open floor plan
Exterior Features
  • Covered front porch
  • Covered rear porch
Special Features
  • Finished lower level
Garage Features
  • Front-entry
  • Tandem
  • Three car+

The basement square footage includes the full area under the garage which calls for suspended concrete above
The basement is designed with a portion to be used by the main floor and a portion to be used as a separate apartment



Purchased as PDF or CAD file

PDF and CAD files are delivered by email, and have no shipping and handling cost.

Purchased as paper plans
* Scroll right to view table
Continental US Canada AK/HI *International
Regular 8 - 12 business days $25 $45 n/a n/a
Priority 3 - 4 business days $40 $90 $55 n/a
Express 1 - 2 business days $55 n/a n/a n/a
Info

There are no reviews

View more
Add your review

Want to modify this plan?

Please submit your requested changes, and our team will email a free modification quote to you within 1 to 3 business days.

Modify this Plan

Starting at

$2,250.00

Additional Options

One-time surcharge for customers wanting to build the structure in reverse. All sets of construction One-time surcharge for customers wanting to build the structure in reverse. All sets of construction drawings in your plan package will come in full reverse essentially flipping the floor plan from left to right with all text, symbols, and notes reading correctly, rather than mirrored. Your order will be fulfilled in right reading reverse format only. The standard format of the construction drawings will not be included with your order. [less] [more]
