Garage Apartment Plan, 062G-0182

Plan 062G-0182
Reverse All Images
All images are copyrighted by our designers. Photos may reflect modifications made by the builder/homeowner.

Carriage house plan designed for a very narrow lot
Tandem garage with half bath accommodates two cars or provides boat storage
Second floor living quarters deliver an open living area with snack bar, full bath, and laundry closet
Vaulted ceiling and deck are thoughtful extras

Heated Square Feet
First Floor 41
Third Floor 520
Total 561
Unheated Square Feet
Deck/Balcony 108
Garage 479
Porch(es) 108
Full Bathrooms 1
Half Bathrooms 1
Width 20 ft. 0 in.
Depth 40 ft. 0 in.
Approximate Height 24 ft. 2 in.
Ceiling Height
First Floor 9 ft. 0 in.
Second Floor 9 ft. 0 in.
Roof Pitch 9/12 Main
Roof Framing
  • Stick
Foundation Options
  • Slab
Exterior Wall Options
  • 2x6
Kitchen Features
  • Eating/Snack bar
Interior Features
  • Vaulted/volume ceiling
  • Laundry
Exterior Features
  • Deck
  • Covered side porch

Carriage house plan designed for a very narrow lot
Tandem garage with half bath accommodates two cars or provides boat storage
Second floor living quarters deliver an open living area with snack bar, full bath, and laundry closet
Vaulted ceiling and deck are thoughtful extras

Purchased as PDF or CAD file

PDF and CAD files are delivered by email, and have no shipping and handling cost.

Purchased as paper plans
* Scroll right to view table
Continental US Canada AK/HI *International
Regular 8 - 12 business days $25 n/a n/a n/a
Priority 3 - 4 business days $40 n/a $55 n/a
Express 1 - 2 business days $55 n/a n/a n/a
