Coastal House Plan, 052H-0140

Plan 052H-0140
Reverse All Images
All images are copyrighted by our designers. Photos may reflect modifications made by the builder/homeowner.

Listed overall depth of 104' includes the stairs, depth is 79' without the stairs

Heated Square Feet
First Floor 1334
Second Floor 1334
Third Floor 936
Lower Level 266
Total 3870
Unheated Square Feet
Carport/Porte Cochere 1225
Bedrooms 4
Full Bathrooms 3
Half Bathrooms 1
Width 29 ft. 0 in.
Depth 104 ft. 0 in.
Approximate Height 48 ft. 0 in.
Ceiling Height
First Floor 10 ft. 0 in.
Lower Level 11 ft. 0 in.
Roof Pitch 4/12 Main
Roof Framing
  • Truss
Foundation Options
  • Piling
Exterior Wall Options
  • 2x6
Kitchen Features
  • Island
  • Eating/Snack bar
Bedroom Features
  • Walk-in closet
  • Upstairs master bedroom
Interior Features
  • Vaulted/volume ceiling
  • Den/office/study
  • Laundry
  • Open floor plan
  • Family room
Exterior Features
  • Covered rear porch
  • Covered front porch
  • Deck
Special Features
  • Elevator
Garage Features
  • Carport
  • Drive-under

Listed overall depth of 104' includes the stairs, depth is 79' without the stairs

Purchased as PDF or CAD file

PDF and CAD files are delivered by email, and have no shipping and handling cost.

Purchased as paper plans
* Scroll right to view table
Continental US Canada AK/HI *International
Regular 8 - 12 business days n/a n/a n/a n/a
Priority 3 - 4 business days n/a n/a n/a n/a
Express 1 - 2 business days n/a n/a n/a n/a
Info

There are no reviews

View more
Add your review

Want to modify this plan?

Please submit your requested changes, and our team will email a free modification quote to you within 1 to 3 business days.

Modify this Plan

Starting at

$3,775.00

Additional Options

One-time surcharge. All sets of construction drawings in your plan package will come in full reverse One-time surcharge. All sets of construction drawings in your plan package will come in full reverse essentially flipping the floor plan from left to right with all text, symbols, and notes reading correctly, rather than mirrored. [less] [more]
