Carriage House Plan, 051G-0077

Plan 051G-0077
Reverse All Images
All images are copyrighted by our designers. Photos may reflect modifications made by the builder/homeowner.

Carriage house plan with Northwest styling
Three-car garage on mail level with two service entries
Second floor apartment includes a bedroom, full bath, and open gathering space
Special extras like a woodstove and kitchen island enhance the living space

Heated Square Feet
Second Floor 896
Total 896
Unheated Square Feet
Garage 896
Bedrooms 1
Full Bathrooms 1
Width 42 ft. 0 in.
Depth 34 ft. 0 in.
Approximate Height 30 ft. 10 in.
Roof Pitch 8/12 Main
Roof Framing
  • Stick and Truss
Garage Door Size(s) 16x8
Garage Door Size(s) 9x8
Foundation Options
  • Slab
Exterior Wall Options
  • 2x6
Kitchen Features
  • Island
Interior Features
  • Vaulted/volume ceiling
  • Great room
  • Open floor plan
Exterior Features
  • Deck
Special Features
  • Fireplace/Woodstove

Carriage house plan with Northwest styling
Three-car garage on mail level with two service entries
Second floor apartment includes a bedroom, full bath, and open gathering space
Special extras like a woodstove and kitchen island enhance the living space
