Duplex Garage Apartment, 050M-0006

Plan 050M-0006
Reverse All Images
All images are copyrighted by our designers. Photos may reflect modifications made by the builder/homeowner.

This special duplex plan was actually taken from a 2-car garage apartment and modified to serve as a multi-family home. Both units offer a two-car garage on the main level with interior stairs leading to the upper level living quarters. The second floor offers an open floor plan with the step-saver kitchen overlooking the great room. The bedroom is comfortably sized and includes ample closet space. Don’t miss the full bath and laundry room.
Units A & B: 689 sf total, 1 bedroom, 1 bath, 2-car garage (573 sf)
We offer a single unit version of this plan. Please see design 050G-0010.

Heated Square Feet
Second Floor 1378
Total 1378
Width 52 ft. 0 in.
Depth 26 ft. 0 in.
Approximate Height 28 ft. 0 in.
Ceiling Height
First Floor 9 ft. 0 in.
Second Floor 9 ft. 0 in.
Roof Pitch 10/12 Main
Roof Pitch 8/12 Secondary
Roof Framing
  • Truss
Foundation Options
  • Slab
Exterior Wall Options
  • 2x4
  • 2x6
Interior Features
  • Great room
  • Laundry

This special duplex plan was actually taken from a 2-car garage apartment and modified to serve as a multi-family home. Both units offer a two-car garage on the main level with interior stairs leading to the upper level living quarters. The second floor offers an open floor plan with the step-saver kitchen overlooking the great room. The bedroom is comfortably sized and includes ample closet space. Don’t miss the full bath and laundry room.
Units A & B: 689 sf total, 1 bedroom, 1 bath, 2-car garage (573 sf)
We offer a single unit version of this plan. Please see design 050G-0010.

Purchased as PDF or CAD file

PDF and CAD files are delivered by email, and have no shipping and handling cost.
