Ranch House Plan, 040H-0005

All images are copyrighted by our designers. Photos may reflect modifications made by the builder/homeowner.

This three-bedroom, three-bathroom Sunbelt home plan offers an open layout promoting easy flow of the daily routine for your living pleasure. The efficient kitchen enjoys views of all the living areas and looks out over the lanai through the sunny nook. Large walk-in closets benefit both the master suite and Bedroom 2, while the study offers quiet, regal relaxation. With the third bath just steps away, it could easily double as a guest room. Don’t miss the deluxe bath outfitting the master suite. The covered lanai can be accessed from the master suite, living room and family room and offers an optional summer kitchen and optional pool bath. Complete with a two-car, side-entry garage and utility room entrance, this ranch home plan delivers relaxed family living Mediterranean style.

Heated Square Feet
First Floor	2665
Total	2665
Unheated Square Feet
Garage	520
Patio/Terrace/Lanai	612
Porch(es)	84
Bedrooms	3
Full Bathrooms	3
Width	51 ft. 0 in.
Depth	98 ft. 2 in.
Approximate Height	24 ft. 0 in.
Roof Pitch	6/12 Main
Roof Framing	Truss
Foundation Options	Slab
Exterior Wall Options	CMU

Kitchen Features	Breakfast area/nook Island Eating/Snack bar
Bedroom Features	Walk-in closet Split bedrooms
Interior Features	Laundry Open floor plan Family room Vaulted/volume ceiling Den/office/study
Exterior Features	Covered front porch Patio/Terrace/Lanai
Garage Features	Two car Side-entry

Purchased as PDF or CAD file

PDF and CAD files are delivered by email, and have no shipping and handling cost.

Purchased as paper plans

* Scroll right to view table

	Continental US	Canada	AK/HI	*International
Regular 8 - 12 business days	n/a	n/a	n/a	n/a
Priority 3 - 4 business days	n/a	n/a	n/a	n/a
Express 1 - 2 business days	n/a	n/a	n/a	n/a

There are no reviews

Add your review

Want to modify this plan?

Please submit your requested changes, and our team will email a free modification quote to you within 1 to 3 business days.

Modify this Plan

Starting at

Select Plan Package Select Foundation Select Exterior Wall

Additional Options

Right Reading Reverse for Plan 040H-0005: $350.00

One-time surcharge for customers wanting to build the structure in reverse. All sets of construction One-time surcharge for customers wanting to build the structure in reverse. All sets of construction drawings in your plan package will come in full reverse essentially flipping the floor plan from left to right with all text, symbols, and notes reading correctly, rather than mirrored. Your order will be fulfilled in right reading reverse format only. The standard format of the construction drawings will not be included with your order. [less] …[more]

Purchase Restrictions:

NOTE: This plan is not available for construction in Lee or Collier County, FL.
