Assisted Living Plan, 012C-0001
All images are copyrighted by our designers. Photos may reflect modifications made by the builder/homeowner.
This commercial building plan is designed for assisted living with handicap accessibility. A covered porch opens to a large and spacious gathering / dining area featuring a cozy fireplace flanked with built-ins. The roomy kitchen boasts an oversized walk-in pantry and serves the dining area with ease. Each bedroom unit is situated on an outside wall boasting outdoor views and a private half bath. A full bath with shower and tub and a double laundry room are located at the heart of the design providing convenience. Perfect for business needs, the office is tucked at the rear of the home with a meeting room located above. This assisted living design offers comfortable accommodations for 15 residents.
| Heated Square Feet | |
| First Floor | 6619 |
| Second Floor | 539 |
| Total | 7158 |
| Bedrooms | 15 |
| Full Bathrooms | 1 |
| Half Bathrooms | 17 |
| Width | 137 ft. 2 in. |
| Depth | 64 ft. 0 in. |
| Approximate Height | 30 ft. 8 in. |
| Ceiling Height | |
| First Floor | 9 ft. 0 in. |
| Roof Pitch | 8/12 Main |
| Roof Framing |
|
| Foundation Options |
|
| Exterior Wall Options |
|
| Kitchen Features |
|
| Interior Features |
|
| Exterior Features |
|
| Special Features |
|
This commercial building plan is designed for assisted living with handicap accessibility. A covered porch opens to a large and spacious gathering / dining area featuring a cozy fireplace flanked with built-ins. The roomy kitchen boasts an oversized walk-in pantry and serves the dining area with ease. Each bedroom unit is situated on an outside wall boasting outdoor views and a private half bath. A full bath with shower and tub and a double laundry room are located at the heart of the design providing convenience. Perfect for business needs, the office is tucked at the rear of the home with a meeting room located above. This assisted living design offers comfortable accommodations for 15 residents.
Purchased as PDF or CAD file
PDF and CAD files are delivered by email, and have no shipping and handling cost.
Purchased as paper plans
* Scroll right to view table
| Continental US | Canada | AK/HI | *International | |
|---|---|---|---|---|
| Regular 8 - 12 business days | $30 | n/a | n/a | n/a |
| Priority 3 - 4 business days | n/a | n/a | n/a | n/a |
| Express 1 - 2 business days | n/a | n/a | n/a | n/a |
